Type: VM Type
Mounting: 1/2” centres
Frequency Response: 20 - 27,000Hz
Channel Separation: 30dB (1kHz)
Output Channel Balance: 1.0dB (1kHz)
Output Voltage: 4.0mV (1kHz, 5cm/sec.)
Vertical Tracking Angle: 23˚
Vertical Tracking Force Range: 1.8 – 2.2g (2.0g standard)
Stylus Shape: Shibata
Stylus Size: 0.26 x 2.7 mil
Stylus Construction: Nude Square Shank
Cantilever Aluminium: Tapered Pipe
Coil Impedance: 2,700Ω (1kHz)
Static Compliance: 40 x 10-6 cm/dyne
Dynamic Compliance: 10 x 10-6 cm/dyne (100Hz)
Recommended Load Impedance: 47,000Ω
Recommended Load Capacitance: 100 – 200pF
Weight: 8.0g
Dimensions: 17.3 (H) x 17.0 (W) x 28.2 (L) mm
Replacement Stylus: VMN50SH
Accessories Included: Cartridge installation screws 5mm ×2 and 10mm ×2, Washer ×2, Hexagon nut ×2, Non-magnetic screwdriver ×1, Brush ×1, Lead wire set ×1
